Texas Instruments TLV905x/TLV905x-Q1 High Slew-Rate Operational Amplifiers are optimized for low voltage operation from 1.8V to 5.5V. The inputs and outputs can operate from rail-to-rail at a very high slew rate. These devices are perfect for cost-constrained applications where low-voltage operation, high slew rate, and low quiescent current are needed. Such applications include large appliances and control of three-phase motors. The capacitive-load drive of the TLV905x/TLV905x-Q1 family is 200pF, and the resistive open-loop output impedance makes stabilization easier with much higher capacitive loads. The TLV905x-Q1 amplifiers are optimized for AEC-Q100 grade 1 applications.
Features
15V/µs high slew rate
330µA low quiescent current
Rail-to-rail input and output
±0.33mV low input offset voltage
5MHz unity-gain bandwidth
15nV/√Hz low broadband noise
2pA low input bias current
Unity-gain stable
Internal RFI and EMI filter
Scalable family of CMOS op amps for low-cost applications
Operational at supply voltages as low as 1.8V
Easier to stabilize with a higher capacitive load due to resistive open-loop output impedance
–40°C to 125°C extended temperature range
Applications
Heating, Ventilating, and Air Conditioning (HVAC)
Photodiode amplifier
Current shunt monitoring for DC motor control
White goods (refrigerators, washing machines, and so forth)
